We have diverse product development experience in the following area of processing machine: such as cutout, engraving, drilling, trimming of moulded parts, and processing of plastic mold.
Processible materials are engineering plastics, super engineering plastics (PEEK, PAI, PPS, PP · PE, PBT, 6N · 66N, PC, ABS, POM · DURACON, MC, nylon ) and so forth.
These materials are used for various purposes such as name plate, display panel of mobile phone, digital camera, automobile meter, major appliance, amusement game, amusement panel, advertising display, game display and so on.
HEIAN has solution for you.
Vertical machining center REX series has made wide range of material processing possible: from plastic resin to light metal.
| |
REX-ⅡB |
|
| |
 |
|
| |
|
|
 |
|
| ■ |
Temperature-unaffected by cartridge spindle. High-precision cutting machine. |
| ■ |
All in one type simple design machine |
| ■ |
Economical space and table moving compact design |
| ■ |
Small amount of air consumption |
| |
REX-ⅡB |
|
| Stroke |
X axis |
(Spindle left/right) |
1,300 mm |
|
| Y axis |
(Table front/back) |
1,300 mm |
|
| Z axis |
(Spindle up/down) |
450 mm |
|
| Table |
1300×1300 mm |
T-slot |
| Rapid traverse |
X axis Y axis = 40 m/min , Z axis = 20 m/min |
|
| Spindle |
Number of spindle |
1 |
AC spindle |
| Speed |
100～15,000 r.p.m. |
| Motor |
2.2/3.7 kW |
| Spindle nose |
NT-30 (40) |
| Tool change |
8 |
|
| Cover |
Included |
|
This is a trimming machine for converted product, and that is high in processing quality, assured dust and noise control, and increased safety.
FP-151PMC
■ Lower height of the table for easy access to remove large-scale material.
■ Trimming and model processing possible
■ Lower machine height for Z stroke
■ Machine cover installed
| |
FP-151PMC-1313 |
FP-151PMC-2113 |
FP-151PMC-2616 |
| Stroke |
X axis (Spindle left/right) |
1,800 mm |
2,600 mm |
| Y axis (Table front/back) |
1,800 mm |
1,600 mm |
2,100 mm |
| Z axis (Spindle up/down) |
450 mm |
800 mm |
| B axis (Spindle tilting) |
± 110° |
| C axis (Spindle swivel) |
± 270° |
| Table |
Size |
1,300 × 1,300 mm |
2,100 × 1,300 mm |
2,600 × 1,600 mm |
| Number |
1 |
| Rapid traverse |
40 m/min |
60 m/min |
| Spindle |
Number of spindle |
1 |
| Speed |
18,000 r.p.m. |
| Motor |
3.7 kW |
| Spindle nose |
NT30 |
| Tool change |
8 |
| NC control |
HEIAN-FANUC |
The NC-131 series covers processing of composite materials flexibly from plastic resin to light metal.
NC-131PMC-2613
■ 18,000 r.p.m high-speed revolution
■ Processible large size material.
| |
NC-131PMC-2613 |
| Stroke |
X axis (Spindle left/right) |
2,600 mm |
| Y axis (Table front/back) |
1,300 mm |
| Z axis (Spindle up/down) |
250 mm |
| Table |
Size |
2,600 × 1,300 mm |
| Number |
1 |
| Rapid traverse |
40 m/min |
| Spindle |
Number of spindle |
1 |
| Speed |
18,000 r.p.m. |
| Motor |
7.5 kW |
| Spindle nose |
NT35 |
| Tool change |
8 |
| NC control |
HEIAN-FANUC |
Vacuum immobilization of large size material. Bring milling, drilling, tapping technology into action with 8- tool- magazine Automatic Tool Change feature.
■ Perfectly suite for processing large size composite material including plastic resin.
■ Multiple process flows are possible by one-time set of material.
| |
ER-131MC-2513/P |
| Stroke |
X axis (Spindle left/right) |
2,500 mm |
| Y axis (Table front/back) |
1,300 mm |
| Z axis (Spindle up/down) |
150 mm |
| Table |
Size |
2,500 × 1,300 mm |
| Number |
1 |
| Spindle |
Number of spindle |
1 |
| Speed |
15,000 r.p.m. |
| Motor |
2.2/3.7 kW |
| Spindle nose |
NT30 |
| Rapid traverse |
30 m/min |
| Tool change |
8 |
| NC control |
HEIAN-FANUC |
Simultaneous processing of multiple spindle head offers efficient-processing and cost-cutting.
Heian has responded to the needs of customers, and is proud of wide variety of multi-axis machine sales achievement. |
|
 |
8 spindle head achieves efficient and accurate cutting-work.
NC-8101PMC-3216
■ Improved User-friendliness by attaching the magazine to the front of the table.
■ Dust-proof construction of the magazine.
■ Material localization diagnosis camera installed.
■ Automatic tool length measurement device installed.
| |
NC-8101PMC-3216 |
| Stroke |
X axis (Spindle left/right) |
1,430 mm |
| Y axis (Table front/back) |
1,900 mm |
| Z1・3・5・7 axis (Spindle up/down) |
150 mm |
| Z2・4・6・8 axis (Spindle up/down) |
310 mm |
| Table |
Size |
3,200 × 1,600 mm |
| Number |
1 |
| Rapid traverse |
30 m/min |
| Spindle |
Number of spindle |
8 |
| Speed |
18,000 r.p.m. |
| Motor |
1･3･5･7spindle |
2.2 kW |
| 2･4･6･8spindle |
7.5 kW |
| Tool change |
5 (linear array) |
| NC control |
HEIAN-FANUC |
This machine is able to control the axes as you need. For example, process large size material into varied shapes by 4 simultaneous controlled spindle head or use 4 different tools for multiple process flow.
It is very flexible.
ER-431P-2113
ER-431P-2513
■ 4 simultaneous controlled spindle head processing enables higher out put than machining center.
■ Cost-effective long-selling basic machine.
■ Perfectly suit for panel processing.
| |
ER-431P-2113 |
ER-431P-2513 |
| Stroke |
X axis (Spindle left/right) |
2,900 mm |
3,300 mm |
| Y axis (Table front/back) |
1,300 mm |
| Z axis (Spindle up/down) |
150 mm |
| Table |
Size |
2,100 × 1,300 mm |
2,500 × 1,300 mm |
| Number |
1 |
| Rapid traverse |
30 m/min |
| Spindle |
Number of spindle |
4 |
| Speed |
18,000 r.p.m. |
| Motor |
4.5 kW |
| NC control |
HEIAN-FANUC |
Automatic spindle open/close system and capable of nesting.
NC-241PMC-2613
■ 18,000 r.p.m high-speed revolution
■ Suitable for simultaneous controlled spindle head processing using different type of tools.
■ Automatic spindle open/close system enables initial set up of 2 different size of materials. We have fixed type and manual open/close system as well.
| |
NC-241PMC-2613 |
| Stroke |
X axis (Spindle left/right) |
2,600 mm |
| Y axis (Table front/back) |
1,300 mm |
| Z axis (Spindle up/down) |
250 mm |
| Table |
Size |
2,600 × 1,300 mm |
| Number |
1 |
| Rapid traverse |
40 m/min |
| Spindle |
Number of spindle |
2 |
| Speed |
18,000 r.p.m. |
| Motor |
7.5 kW |
| Spindle nose |
NT35 |
| Center distance |
350 ～ 1,300 mm servo-controlled |
| Tool change |
8 |
| NC control |
HEIAN-FANUC |
Reduced spindle power to 3.7 kW 2 parallel spindle head CNC router for small size material.
RE-231P-1008
■ Space-saving
■ Ideal for education-related as it is entry-level machine.
■ Despite small size machine, equipped same basic performance as middle and big size machine.
■ Machine cover is an option.
| |
RE-231P-1008 |
RE-231P-2113 |
| Stroke |
X axis (Spindle left/right) |
1,200 mm |
2,900 mm |
| Y axis (Table front/back) |
800 mm |
1,300 mm |
| Z axis (Spindle up/down) |
150 mm |
| Table |
Size |
1,000 × 800 mm |
2,100 × 1,300 mm |
| Number |
1 |
| Spindle |
Number of spindle |
2 |
| Speed |
18,000 r.p.m. |
| Motor |
3.7 kW |
| Center distance |
200～500 mm |
250 mm |
| NC control |
HEIAN-FANUC |
| |
