This is versatile gantry CNC machine.
The table is 26 meters long, and only one initial setup is needed even for very long material. It enables efficient manufacturing under limited conditions.
| |
NG-471PBSMC-20260 |
| Stroke |
X1, 2 axis |
800 mm |
| X3 axis |
2,550 mm |
| Y axis |
28,500 mm |
| Z1, 2 axis |
400 mm |
| Z3 axis |
400 mm |
| Table |
Size |
800 mm × 26,000 mm |
| Number |
2 |
| Rapid traverse |
X1, 2 axis |
10 m/min. |
| X3 axis |
10 m/min. |
| Y axis |
10 m/min. |
| Z1, 2 axis |
6 m/min. |
| Z3 axis |
6 m/min. |
| Spindle |
No.1, 2 ATC router spindle |
Motor |
2P-7.5/11 kW |
| Speed |
10,000 r.p.m. |
| Spindle nose |
NT40 |
| No.3 Saw spindle |
Motor |
5.5 kW |
| Speed |
3,600 r.p.m. |
| Saw diameter |
φ600 mm |
| Cutting thickness |
200 mm |
| No.4 Drill spindle |
Motor |
4P-2.2 kW |
| Speed |
160～200 r.p.m. |
| Hole diameter |
φ60 mm |
| Drill length |
400 mm |
| Tool change |
|
12 |
| NC control |
HEIAN-FANUC |
This is a machine for boring, light cutout, molding of alminum material. For example, finish processing of louver and processing of aluminum frame. Four sides tapping is possible as well. Avoiding interference with the work and spindle head by tilting and swiveling of the spindle head makes efficient three dimensional processing possible.
| |
NC-151MC-1330 |
| Stroke |
X axis (Table front/back) |
3,600 mm |
| Y axis (Spindle left/right) |
1,900 mm |
| Z axis (Spindle up/down) |
800 mm |
| B axis (Spindle tilting) |
±90° |
| C axis (Spindle swivel) |
±210° |
| Table |
Size |
1,300 × 3,000 mm |
| Number |
1 |
| Rapid traverse |
X, Y axis |
30 m/min. |
| Z axis |
10 m/min. |
| B, C axis |
3000°/min. |
| Spindle |
Number of spindle |
1 |
| Speed |
18,000 r.p.m. |
| Motor |
7.5/11 kW |
| Spindle nose |
NT40 |
| Tool change |
|
16 |
| NC control |
HEIAN-FANUC |
The machine meets the specific needs of the aerospace industry. In terms of accuracy, automatic tool length measurement device, feedback scale, 3D probe are installed. Also, using torque tandem control for optimum control of the gantry head. The five-axis router and yet dust collecting system is installed and environmentally friendly.
| |
NG-151MC-30110 |
| Stroke |
X axis (Spindle front/back) |
12.500 mm |
| Y axis (Spindle left/right) |
4,250 mm |
| Z axis (Spindle up/down) |
600 mm |
| A axis (Spindle tilting) |
±45° |
| C axis (Spindle swivel) |
±210° |
| Table |
Size |
3,000 × 11,000 mm |
| Number |
1 |
| Rapid traverse |
X, Y axis |
15 m/min |
| Z axis |
10 m/min |
| A, C axis |
3000°/min. |
| Spindle |
Number of spindle |
1 |
| Speed |
20,000 r.p.m. |
| Motor |
7.5/11 kW |
| Spindle nose |
NT40 |
| Tool change |
|
16 |
| NC control |
HEIAN-FANUC |
Vacuum immobilization of large size material.
8- tool- magazine Automatic Tool Change feature enables various processing like drilling, milling and tapping.
| |
ER-131MC-2513/P |
| Stroke |
X axis (Spindle left/right) |
2,500 mm |
| Y axis (Table front/back) |
1,300 mm |
| Z axis (Spindle up/down) |
150 mm |
| Table |
Size |
2,500 × 1,300 mm |
| Number |
1 |
| Spindle |
Number of spindle |
1 |
| Speed |
15,000 r.p.m. |
| Motor |
2.2/3.7 kW |
| Spindle nose |
NT30 |
| Rapid traverse |
30 m/min |
| Tool change |
|
8 |
| NC control |
HEIAN-FANUC |
|
|
